SENECA Z-4TC輸入模塊,Z-4TC輸入模塊
SENECA Z-4TC輸入模塊,Z-4TC輸入模塊產品資料：
意大利SENECA Z-4TC輸入模塊參數特點：
| Order code : | Z-4TC | |
| Description: | 4-CH thermocouple input module / RS485 | |
| Power supply: | 10..40 Vdc; 19..28 Vac (50-60 Hz) | |
| Transducers supply: | 20 Vdc, 20 mA | |
| Dimensions: | 17,5 x 100 x 112 [mm] | |
| Mounting: | DIN 46277, 35 mm symmetrical rail | |
| Input: | 4-CH bipolar voltage ±80 mV or thermocouples type J,K,R,S,T,B,E,N | |
| Resolution: | 14 bit + sign | |
| Communication: | RS485 2 wire, ModBUS RTU slave protocol |
